Wear Plate

Home » Products » Mud Pump Parts » Wear Plate

The wear plate is a kind of pump accessory for the fluid end of mud pump in oil drilling. It has the function of sealing and pressure maintaining for a hydraulic cylinder. All wear parts made by RUNDONG Company adopt high end alloy carbon steel made by domestic steel plants. These wear resistant steel plates have experienced the high temperature forging, heat treatment and CNC machining process, which guarantees geometric size, sealing performance, increased abrasion resistance and durability. Different models and types of wear plate (liner) products and related jackscrews can be offered upon request.

Mud Pump Model List

Bomco/ Emsco	F-1300	FB-1300	F-1600	FB-1600	FA-1300	FA-1600	FC-2200	F-1000	F-800	F-500
	F-350	DB-550	D-700	DA-700	D-300/500	D-375
National	7P50	8P80	9P100	10P130	12P160	14P220	N1300	C-250	E-700	G-100
	K-500	K-380	K-500A	K-700A	C-250	C-350	JWS-400
Gardner Denver	PZ7	PZ8/9	PZ10/11	FK-FXK	FY-FXX	FG-FXG	FF-FXP	KG-KXG	FQ-FXQ	FF-FXF
Oilwell	A-560-PT	A-600-PT	A-850-PT	A-1100-PT	A-1400-PT	A-1700-PT
Russian	UNBT-950	UNB-600	8T-650	NBT600	UNB1180	UNBT1180L	3PN1600	E1600
Ideco	T-500	T-800	T-1000	T-1300	T-1600
Wirth	TPK1000	TPK1600	TPK2000
LS National	3NB-500C	3NB1000C	3NB1300C	3NB1600	3NB800	3NB1300A
Ellis	E-447	E-2200
Drillmec	9T1000	12T1600
OTHER BRANNER: HONGHUA, QINGZHOU, WIRTH, OPI, ELLIS WILLIAMS,WILSON, GASO, SKYTO, BREWSTER, WETHERFORD

Related Names
Mud Pump Wear Plate︱Mud Pump Replacement Parts︱Fluid End Parts | Sealing Disk
